Never content, Lumin have constantly been evaluating their streamers to see if there was any possible way to beat them. It's taken years, but finally they're ready to reveal Streaming's New Cutting Edge.
With huge dynamics, imaging, and tonal quality improvements from the S1, the X1 represents the pinnacle of what is possible in the server/streamer marketplace today.
Re-engineered throughout
LUMIN X1 makes improvements in every possible location:
New processor delivers native DSD512 & PCM768 playback
Dual Mono design throughout maximises channel separation
Dual ES9038Pro SABRE DACs featuring 140dB dynamic range
Femto Clock System with precision FPGA distribution
New Output Buffer design
Dual Mono dual stage linear regulator
Optical Network provides complete isolation from network digital noise
USB Digital Audio Output supports Native DSD512
Specs
X1 SPECIFICATION
DSD SUPPORT:
Up to DSD512 22.6MHz, 1-bit
PCM SUPPORT:
Up to 768kHz, 16–32-bit, Stereo
ANALOG OUTPUT STAGE:
Dual ESS SABRE32ES9038Pro DAC chips
Fully balanced layout with high-quality components
Output connectors coupled with dual LUNDAHL LL7401 output transformers
Femto Clock System with precision FPGA distribution
UPSAMPLING RATES & BIT DEPTHS:
DSD128 upsampling option for all files
PCM 384kHz upsampling option for all files
DIGITAL OUTPUT STAGE:
USB:
Native DSD512 support
PCM 44.1–768kHz, 16–32-bit, Stereo
BNC SPDIF:
PCM 44.1kHz–192kHz, 16–24-bit
DSD (DoP, DSD over PCM) 2.8MHz, 1-bit
OPTICAL NETWORK:
Industry-standard SFP
1000Base-T Gigabit Ethernet
Adapter may be needed for your particular switch/cables
Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)
POWER SUPPLY:
External solid billet cnc dual-toroidal
Separate digital & analogue circuitry
Low-noise linear regulator
9-pin Output Connector
PHYSICAL:
FINISH:
Black anodised brushed aluminium (with matching PSU)
Raw brushed aluminium (with matching PSU)
LUMIN (SOLID ALUMINIUM CHASSIS):
350mm (W), 345mm (D), 60mm (H), 8kg
PSU (SOLID ALUMINIUM CHASSIS):
106mm (W), 334mm (D), 60mm (H), 4kg
SPECIFICATION FOR ALL LUMIN MUSIC STREAMERS
STREAMING PROTOCOL:
UPnP AV protocol with audio streaming extension (OpenHome)
Roon Ready
TIDAL Connect
Spotify Connect
AirPlay-compatible
Gapless Playback
On-Device Playlist
APP FEATURES:
Native support for TIDAL, MQA, Qobuz and TuneIn Radio.
Tidal MQA icons to identify high-res music
Qobuz high-res icons to identify high-res music
Volume control
High-resolution artwork
Artwork caching
Search
Multiple tag handling
Composer tag support
Album-grouping in playlist
Automatic internet links to artists/album/songs
Saving and restoring of playlists (including Tidal and Qobuz)
SUPPORTED AUDIO FILE FORMATS:
DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)
PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF
Compressed (lossy) Audio: MP3
MQA
INPUT:
Ethernet RJ45 network 1000Base-T
USB storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only)
ANALOGUE AUDIO OUTPUTS:
XLR balanced, 6Vrms, pin 2 Hot
RCA unbalanced, 3Vrms
SUPPORTED CONTROL DEVICES:
All models of Apple iPad (v2 or later). iOS 8.0 or later required. Full Retina Display support.
Android devices. Android 4.0 (Ice Cream Sandwich) or later required
OTHER:
Leedh Processing lossless digital volume control
Programme of Continuous Development – Firmware-upgradable for further features and enhancements
