The Parasound ZoneMaster ZM2350, is a powerful and affordable 350-watt per channel Class D stereo power amplifier with built-in subwoofer crossover, perfect for custom installation and premium audio applications.
The two-channel ZoneMaster ZM2350 draws on the company's renowned heritage of low-noise class AB input stages and analogue bass management, combined with the highest quality Class D amplification to drive 8-ohm speakers to 350 watts per channel and up to 600 watts into 4-ohms. As with all Parasound amplifiers, the 2350's high current design and extensive heat-sinking enable it to easily drive 2-ohm loads in demanding applications.
In addition to providing high power and audiophile-grade sound quality to stereo speakers, the ZoneMaster 2350 includes installer-friendly features that have proven very popular on Parasound's other ZoneMaster amplifiers. These include a two-channel analogue 80Hz, 24dB/octave low-pass crossover for driving up to four 8-ohm passive subwoofers with 300 watts per sub, without the need for external crossovers. A mono mode permits use of up to eight 8-ohm full-range mono speakers, perfect for applications where stereo sound is not required, such as bars and restaurants.
Each channel features a separate level control, useful to limit the output when using speakers with in-wall volume controls, for left/right balance adjustment to compensate for room placement or to restrict the maximum level in a particular zone. A and B speaker switches, a stereo/mono switch and a switchable 30Hz/80Hz high-pass filter, to improve performance with small speakers, provide flexibility of set up. Both line level and speaker level inputs are catered for, with the option to daisy chain both at line level to another amplifier. The 2350 also features a mono full range line level output and an 80Hz low pass line level output for use with an active subwoofer. Audio-sensing or 12 Volt trigger auto turn-on options complete the line-up of installer friendly features.
"While this is probably my 38th new power amplifier introduction, I am especially excited about the ZoneMaster 2350 as something new and different for Parasound," said Richard Schram, the company's president and founder. "It has the high horsepower our industry has come to expect from good Class D, and by marrying it with our industry-leading analogue input stage and unique connectivity options, we've created a remarkably rugged, maximum-fidelity amp that can play at the red-line all day. With bass management and versatile installation features, it is also a really practical choice for commercial systems."
So if you are looking for a ultra-flexible but seriously great sounding single zone powerful amplifier (and looking at better subwoofer integration), and one that can be used for a multitude of high performance custom installation situations, then you cannot look any further than the new Parasound ZM2350 - it is a must for any serious custom installation professional and project.
Parasound ZoneMaster ZM2350 - Universal Two Channel Amplifier with Sub Crossover - Features & Benefits:
350 watts x 2 @ 8 Ω
600 watts x 2 @ 4 Ω
2 Ω stable for driving multiple speaker pairs
Two pairs of speaker outputs with A/B buttons
Lockout switch on rear panel to disable A/B buttons
High pass filter, switchable for 30Hz or 80Hz
Automatic on/off by 12V trigger w/ looping output
Automatic on/off by audio signal
Speaker level input enables integration with systems lacking preamp output jacks
Parasound designed class AB input stage w/ premium Class D power stage
Subwoofer mode for driving multiple in-wall subs without the need for an external crossover
Mono mode combines L and R for single speaker applications
Mono full range preamp output
Subwoofer 80Hz, 24dB/oct. low pass preamp output
Looping left and right output jacks
Left and right input level controls
Efficient, low heat design
Short circuit and overload protection
0.5 watt standby power consumption meets EU and Energy Star requirements
2U rack mounting hardware is included in box
50 watts x 2 @ 8 Ω
90 watts x 2 @ 4 Ω or 2 Ω
160 watts x 1 @ 8 Ω (Bridged Mode)
200 watts x 1 @ 4 Ω (Bridged Mode)
Low Pass Crossover:
80 Hz, 18 dB per octave
Minimum Speaker Impedance:
Stereo Mode: 2 Ω
Bridge Mode: 4 Ω
*Note: Operation at these minimum impedances might require additional ventilation.
10 Hz - 60 kHz, +0/-3 dB
Total Harmonic Distortion:
< 0.05 % at typical listening levels
< 0.9 % at full power
70 dB at 20 kHz
700mv = Full output (50 Watts @ 8 Ω)
Total gain = 29 dB (Level controls set to Maximum)
> 112 dB, input shorted, IHF A-weighted
DC Trigger Requirements:
+9 Vdc to +12 Vdc, 5 mA
Audio Trigger Requirements:
2 mV audio signal (5-8 minutes turn off delay)
AC Power Requirement:
250 Watts maximum
15 Watts typical (music playing)
7.5 Watts idle (no music playing)
0.5 Watts in standby Dimensions:
Width: 8.5” (220 mm)
Depth: 10” (254 mm)
Depth: 12” (305 mm) with AC cord and cables connected
Height, with feet: 2” (51 mm)
Height, without feet: 1.75” (45 mm), 1U Weight: Net: 4.0 lbs. (1.8kg)
Shipping: 7.0 lbs. (3.1 kg)
