Ortofon

Ortofon Quintet Blue Cartridge

Ortofon Quintet Blue Cartridge

BUY WITH CONFIDENCE We are a 2 x Global Award Winning Retailer
Read More
FREE 5 YEAR WARRANTY INCLUDED FREE 5 year warranty included on this item
GET IT IN TIME FOR CHRISTMAS! Order now, have it in time for Christmas!
Regular price £459.00
Regular price Sale price £459.00
Sale Sold out
VAT included.

Part Exchange / Trade In Quote?

Nothing demonstrates Ortofon's long-standing resilience more than its commitment to the refinement of analogue sound quality and its continued development of new cartridge models. Since 1948 Ortofon have introduced about 100 different moving coil models, with their latest being the Quintet Series.

Ortofon believe the cartridges in this new series are more than worthy successors to the long line of models that have made Ortofon the global leader in the manufacturing and supplying of phono cartridges.

The Quintet Blue is a very homogeneous cartridge whose sound image will tend to more smooth reproduction compared to Quintet Red and moderate dynamic strength compared to Quintet Bronze.

It features a Nude Elliptical diamond mounted on an aluminium cantilever. The Quintet Blue will bring more space, depth and detail into the sound and is a very good choice for any kind of music, especially rhythmic.

The MC Quintet Series is congruent with Ortofon’s unrelenting commitment to providing the most precise and accurate reproduction possible without colouration.

Key Features:

  • Light weight and durable cartridge body made from a special ABS (Acrylonitrile/Butadiene/Styrene) thermoplastic material
  • Neodymium magnets are implemented to achieve an optimal output
  • Delivers more space, depth and detail into the sound and is a very good choice for any kind of music, especially rhythmic
  • Low internal impedance makes the cartridge less sensitive to load and therefore ensures compatibility with the widest range of preamps and transformers
  • Supplied with 2 screws (M2.5 x 5)
  • Nude Elliptical stylus profile
Specs
Output Voltage (at 1kHz, 5cm/sec): 0.5mV
Channel Balance at 1kHz: <1.5dB
Channel Separation at 1kHz: >21dB
Channel Separation at 15kHz: >14dB
Frequency Range (at -3dB): 20 Hz - 25 kHz
Frequency Response 20Hz - 20kHz: ± 2.5dB
Tracking Ability at 315Hz: 70μm
Compliance, Dynamic, Lateral: 15μm / mN
Stylus Type: Nude Elliptical
Stylus Tip Radius r / R: 8 / 18μm
Tracking Force Range: 2.1 - 2.5g (21 - 25mN)
Recommended Tracking Force: 2.3g (23mN)
Tracking Angle: 20º
Internal Impedance / DC Resistance:
Recommended Load Impedance: >20Ω
Cartridge Body Material: ABS/Alu.
Cartridge Colour: Blue
Cartridge Weight: 9g
