The Statement Series of wooden cartridges are a fixed coil design, hand-crafted at Grado Labs in Brooklyn. An intricate procedure of curing is done between production steps to achieve optimal sonic quality. This series generator/stylus module is not replaceable* allowing a one-piece magnetic circuit and a reduction of chassis resonances. The Statement Series utilizes manufacturing and assembly techniques of fantastic accuracy and precision, and the result is virtual perfection. Should be used only with the finest equipment. Recommended tracking force 3/4 to 2 grams.
The Master2 and Reference2 models use a five piece OTL cantilever technology achieving an additional 5% tip mass reduction over the Platinum2 and Sonata2 models. The coils are wound with ultra-high purity long crystal (UHPLC) oxygen free copper wire. The Master2 model is mounted with Grado's specially designed nude elliptical diamond, and the Reference2 model uses Grado's true ellipsoid design diamond. These cartridges are individually calibrated.
Specs
- OUTPUT: 1mV @ 5 CMV
- CONTROLLED FREQUENCY RESPONSE: 10-60 KHZ
- CHANNEL SEPARATION: AVERAGE 40 DB - 10-30 KHZ
- LOAD: 47,000 OHMS
- INDUCTANCE: 30 mh
- RESISTANCE: 72 OHMS
- NON SENSITIVE TO CAPACITIVE LOAD
- CHASSIS MASS: 10 GRAMS
- TRACKING FORCE: 1.5 - 1.9 GRAMS
