| Construction principle |
Acoustically optimized drive shape Base support plate 50 mm Ø 180mm and feet made of solid aluminum Resonance optimized and decoupled via special Teflon discs and silicone mixture Damper height adjustment via threaded spikes, decoupled via special felt feet |
|---|---|
| Speed range |
Convenient speed switching at the touch of a button 33.3, 45 rpm Fine adjustment + or – possible at any time at the touch of a button |
| camp |
Ground stainless steel axle , cast bushing, ruby bearing base with special Teflon discs, resonance-optimized with polished ceramic ball |
| drive |
Berger Lahr synchronous motor with belt drive Belt made of nylon silicone mixture Microprocessor controlled electronics |
| turntable |
Made of solid aluminum 7 kg turntable thickness 35 mm CNC precision turned and polished by hand |
| Turntable support |
Support mat made of genuine leather 4mm plexiglass support |
| synchronization | 0.08% (measured with Ortofon measuring computer) |
| Electrics/power supply |
240 volts 47-63 hertz 0.4 amps output 32 volts 0.46 amps maximum switching power supply with cold device plug cable |
| total weight | 12 kg weight without tonearm |
| Weight | 12kg |
|---|---|
| Size | 31 × 31 × 17cm |
| scope of delivery |
1 record player |
| material |
aluminum |
| Tonearm |
WTB 370 including high-quality pickup system |
| steering |
Microcontroller M2 with quartz generator and fine regulation, plug and play |
