OVERVIEW
- Dual ES9068 D\A converter chip, independent decoding for dual channel.
- The 3rd generation XMOS XU316 with higher performance and faster speed.
- High precision, low jitter dual clock oscillators synchronous processing.
- Up to DSD512 Native, PCM768Hz@32Bit decoding.
- Optical, Coaxial and USB support MQA full decoding and rendering.
- Qualcomm QCC5125 Bluetooth 5.0 module, APTX HD/LDAC protocol.
- Fully balanced audio architecture, differential amplifier circuit and professional calibration.
- High-performance headphone amp output, 16-300 ohm headphone driver.
- 3-inch LCD screen, with diverse VU meter modes.
- Low ripple power supply to ensure a purer power source.
- Exclusive mobile phone controller APP for global control.
SPECIFICATIONS
Model | EverSolo DAC-Z6 |
Display Screen | 3-inch LCD Screen |
Chassis | Aluminum alloy |
DAC | ES 9068*2 |
Audio Processor | XMOS XU316 |
OPA Chip | RT 6863*6 |
Power Supply | Low noise switching power supply |
Bluetooth Audio Input | Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC/aptX/aptX LL/aptX HD/LDAC Bluetooth protocol |
USB-B DAC Input | Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA |
USB-C DAC Input | Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA |
Optical Audio Input | Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA |
Coaxial Audio Input | Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA |
Analog Audio Output | Preamp output: XLR (balanced), RCA; Headphone amp output: 6.35mm single-ended |
USB Port | USB2.0*1(only for firmware upgrade) |
Control Methods | Remote control, mobile APP control and knob control |
Headphone Impedance | 16-300Ω (low gain mode:16-32Ω/high gain mode: 32-300Ω) |
XLR Audio Output | Output Level(Vrms):4.1Vrms@0dBFS THD+N@A-wt:0.000094%@1kHz(-120dB@1kHz) THD+N@No-wt:0.000117%@1kHz(-118dB@1kHz) Noise@No-wt :<3uVrms SNR)@No-wt:125@1kHz frequency response:20Hz-20kHz(±0.15dB) CROSSTALK:-123dB@1kHz DNR)@No-wt:125dB@1kHz |
RCA Audio Output | Output Level(Vrms):2.1Vrms@0dBFS THD+N@A-wt:0.000116%@1kHz(-118dB@1kHz) THD+N@No-wt:0.000138%@1kHz(-117dB@1kHz) Noise@No-wt :<2.5uVrms SNR)@No-wt:21dB@1kHz frequency response:20Hz-20kHz(±0.15dB) CROSSTALK:-118dB@1kHz DNR)@No-wt:121dB@1kHz |
Headphone (low gain mode) | Output Level(Vrms):1.2Vrms@0dBFS Max Power:: 45 mW@32Ω THD+N@A-wt:0.00028%@1kHz(-111dB@1kHz) THD+N@No-wt:0.00031%@1kHz(-110dB@1kHz) Noise@No-wt :<3.5uVrms SNR)@No-wt:114dB@1kHz frequency response:20Hz-20kHz(±0.15dB) DNR)@No-wt:114dB@1kHz |
Headphone (high gain mode) | Output Level(Vrms):2.8Vrms@0dBFS Max Power: 26 mW@300Ω THD+N@A-wt:0.00014%@1kHz(-117dB@1kHz) THD+N@No-wt:0.00016%@1kHz(-116dB@1kHz) Noise@No-wt :<3.5uVrms SNR)@No-wt:121dB@1kHz frequency response:20Hz-20kHz(±0.15dB) DNR)@No-wt:121dB@1kHz |
Power Input | AC 110~240V 50/60Hz |
Rated Power | 9W |
Dimensions | 270mm(W) * 187mm(D)* 50mm(H) |
Packing List | Remote control*1, power cable*1, product manual*1 |
