Entry level moving magnet cartridge
The new Pick it MM E
The phono cartridge is one of the most sound-forming and sonically critical part of a turntable. It transforms the physical grooves of a record into an electrical signal. This signal determines the base quality of the music playback. Moving-Magnet (MM) cartridges are the most common and affordable solution. These can be manufactured less expensive compared to Moving-Coil (MC) and an additional advantage is the replaceable stylus. Our goal was to design a cartridge which delivers a high quality music playback while keeping the price as low as possible. The Pick it MM E is the perfect starting point for every budget vinyl lover.
Ultimate price-performance ratio
The Pick it MM E uses a low mass system which is realized with a miniature neodymium generator magnet. Due to the lower inertia the result is a clear improvement of tracking accuracy. The conical diamond tip delivers a warm and smooth high quality audio reproduction with low background noise. The enclosure is made of resonance optimized ABS which results in a total weight of around 5,5 grams. The highly damped body effectively reduces mechanical vibration induced colorations to a vanishing level.
Features
- NEW entry level Pick it MM cartridge
- NEW Pro-Ject Audio cartridge design
- Low mass moving magent system
- Improved tracking due to low inertia
- Highly damped ABS body reduces mechanical vibration
- Very low colouration and low noise playback
- Musical all-purpose cartridge
- Conical diamond
- 1/2 inch mounting standard
- Special design protects the stylus
Technical Specifications
| Cartridge principle: | MM (Moving-Magnet) |
| Output voltage at 1 kHz: | 3,8 mV (3,54 cm/sec) |
| Tracking ability at 315Hz: | 70 μm |
| Dynamic compliance: | 14 μm/mN |
| Frequency response: | 10 - 20 000 Hz +/- 2dB |
| Stylus type: | Conical |
| Tracking force, range: | 1,8 - 2,2 g (mN) |
| Tracking force, recommended: | 2,0 g (mN) |
| Height stylus tip to top mounting surface: | 18,2 mm |
| Tracking angle: | 23° |
| Recommended load resistance: | 47 kΩ |
| Cartridge weight: | 5,5 g |
