Pro-Ject Amp Box S3 Integrated Amplifer
Pro-Ject Amp Box S3 Integrated Amplifer
Couldn't load pickup availability
Part Exchange / Trade In Quote?
Part Exchange / Trade In Quote?
The Amp Box S3 is an efficient, yet capable, compact power amplifier with true stereo hi-fi credibility. Thanks to its clever internal design it delivers a warm, inviting musical performance with the sonic characteristics of a tube amplifier.
The Amp Box S3 boasts a new PCB concept and sophisticated topology in order to achieve less distortion and a better signal to noise ratio. This audio-focused internal design is also highly efficient, with very little wasted energy. It also brings you a rich and musical sound with a touch of analogue warmth, inspired by the sonic traits of more costly valve amplifiers. By squeezing this clever technology into a deceptively small footprint, the amplifier is suited to a variety of applications.
Ideally suited to room sizes up-to 15m2, depending on the matched speakers, the Amp Box S3 can be useful for nearfield hi-fi systems, powering in-wall or in-ceiling speakers, or for enhancing the performance of existing hi-fi and home cinema systems. With one stereo RCA input, a jack output, and trigger connections, it’s also possible to stack multiple amplifiers for bi- or tri-amplified systems.
Sitting on four rubberised feet and contained within a sturdy metal casework that boasts a clean, minimalist elegance for when it’s on show, the Amp Box S3 is designed to protect itself from electronic interference and vibration. The result is a purer musical signal that is true to the original recording, all presented in a spacious and comfortable sound stage.
Features
- NEW PCB concept & sophisticated topology
- NEW lower distortion & better SNR
- Ultra compact & audiophile
- Advanced amplifier module
- Metal casing protects against vibration and interference
- Made in Europe
Technical Specifications
| Power output | 2 x 23 W / 40 W at 8 ohms / 4 ohms |
| Peak power | 2 x 50 W at 4 ohms |
| Frequency response | 20Hz - 20kHz (- 0,7dB / 4 ohms) |
| Channel separation | > -68 dB @ 20kHz |
| Signal-to-noise ratio | 87dBV (100dBV-‚A‘ weighted)/4ohms |
| THD | < 0,02% @ 10W / 4 ohms |
| Gain | 31 dB |
| Input | 1 pair RCA sockets |
| Input impedance | 25 kohm |
| Speaker sockets | 4mm Ø Banana, spades. pins or bare wire |
| Trigger 12V DC | In&Out, 2-pole jack socket Ø 2,5mm |
| Power supply | 20V/3A DC (universal power supply) |
| Dimensions W x H x D | 103 x 36 x 118mm |
| Weight | 385g without power supply |
