Audio Technica

Audio Technica AT-PEQ30 Phono Stage

Audio Technica AT-PEQ30 Phono Stage

BUY WITH CONFIDENCE We are a 2 x Global Award Winning Retailer
Read More
FREE 5 YEAR WARRANTY INCLUDED FREE 5 year warranty included on this item
Regular price $ 4,264.00
Regular price Sale price $ 4,264.00
Sale Sold out

Part Exchange / Trade In Quote?

The AT-PEQ30 phono equalizer is designed specifically to upgrade a turntable with a built-in phono amplifier or to add a phono. It is compatible with turntables with VM (dual magnet), MM (moving magnet), and MC (moving coil) cartridges. The PEQ30 benefits from Audio-Technica’s years of analogue audio expertise and uses the finest quality parts in a layout that is optimized for low noise and minimum distortion.

Features
  • Selectable MM and MC input with fixed gain and impedance allows for compatibility with a wide range of moving magnet and moving coil cartridges
  • High-quality FET inputs ensure a low noise signal when incorporated with a negative feedback-type phono equalizer circuit
  • Precision components provide an excellent RIAA response for best-in-class performance
  • The all metal construction enclosure provides superior isolation from radio and electronic noise interference
  • The machined aluminium front panel and gold-plated input/output RCA connectors are examples of the high-grade material used throughout
Specs
Input Impedance MM type: 47 kiloohms
MC type: 120 ohms
Input Sensitivity MM type: 4.5 mV
MC type: 0.28 mV
Rated Output MM type: 250 mV
MC type: 250 mV
Gain MM type: 35 dB
MC type: 59 dB
Signal-to-Noise Ratio MM type: 100 dB
MC type: 74 dB
RIAA Deviation (20 to 20,000 Hz) MM type: ±0.5 dB
(20 to 20,000 Hz) MC type: ±0.5 dB
Power Supply DC 15 V, 1.2 A
Power Consumption 2.5 W
Dimensions 47 mm (1.85") H x
197.5 mm (7.78") W x
125.5 mm (4.94") D
(excluding protrusions)
Weight About 890 g
Accessories Included AC adapter
