Eversolo DAC-Z8 DAC

Eversolo DAC-Z8 DAC

Why Buy From Kronos AV? Here are just a few reasons...
Read More
FREE 5 YEAR WARRANTY INCLUDED FREE 5 year warranty included on this item
Regular price €707,95
Regular price Sale price €707,95
Sale Sold out
VAT included.

Part Exchange / Trade In Quote?

OVERVIEW

  • ESS Sabre flagship ES9038Pro 32 bits D\A converter chip.
  • The 3rd generation XMOS XU316 with higher performance and faster speed.
  • High precision, low jitter dual clock oscillators synchronous processing.
  • OPA1612*8 I/V operational amplifier circuit, 8-channel shunt compensation technology.
  • Up to DSD512 Native, PCM768KHz@32Bit decoding.
  • Optical, Coaxial and USB support MQA full decoding and rendering.
  • Qualcomm QCC5125 Bluetooth 5.0 module supports APTX HD/LDAC protocol.
  • Fully balanced audio architecture, differential amplifier circuit and professional calibration.
  • High-performance headphone amp output, 16-300 ohm headphone driver.
  • 3-inch LCD screen, with diverse VU meter modes.
  • Low ripple power supply to ensure a purer power source.
  • Exclusive mobile phone controller APP for global control.

SPECIFICATIONS

Model EverSolo DAC-Z8
Display Screen 3-inch LCD Screen
Chassis Aviation aluminum alloy
DAC ES 9038Pro
Audio Processor XMOS XU316
OPA Chip OPA1612*10
Power Supply Low noise switching power supply
Bluetooth Audio Input Qualcomm QCC5125 Bluetooth module, BT5.0
Support SBC/AAC/aptX/aptX LL/aptX HD/LDAC Bluetooth protocol
USB-B DAC Input Compatible with Windows (7, 10), Mac, Android and IOS
Up to stereo DSD512, PCM 768KHz 32Bit and MQA
USB-C DAC Input Compatible with Windows (7, 10), Mac, Android and IOS
Up to stereo DSD512, PCM 768KHz 32Bit, MQA
Optical Audio Input Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
Coaxial Audio Input Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
Analog Audio Output Preamp output: XLR (balanced), RCA;
Headphone amp output: 6.35mm single-ended
USB Port USB2.0*1(only for firmware upgrade)
Control Methods Remote control, mobile APP control and knob control
Headphone Impedance 16-300Ω (low gain mode:16-32Ω/high gain mode: 32-300Ω)
XLR Audio Characteristics Output level(Vrms): 4.1Vrms@0dBFS
THD+N@A-wt: 0.000062%@1kHz(-124dB@1kHz)
THD+N@No-wt:0.000069%@1kHz(-123dB@1kHz)
Noise@No-wt: <1.2uVrms
SNR @No-wt: 133dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
Crosstalk: -130dB@1kHz
DNR @No-wt: 133dB@1kHz
RCA Audio Characteristics Output level (Vrms): 2.3Vrms@0dBFS
THD+N@A-wt: 0.000086%@1kHz(-121dB@1kHz)
THD+)@No-wt: 0.000097%@1kHz(-120dB@1kHz)
Noise @No-wt: <1.5uVrms
SNR @No-wt: 126dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
Crosstalk: -123dB@1kHz
DNR@No-wt: 126dB@1kHz
Headphone (low gain mode) Output level(Vrms): 1.2Vrms@0dBFS
Maximum undistorted power: 45 mW@32Ω
THD+N@A-wt: 0.00015%@1kHz(-116dB@1kHz)
THD+N@No-wt: 0.00018%@1kHz(-115dB@1kHz)
Noise @No-wt: <2uVrms
SNR@No-wt: 124dB@1kHz
Frequency response: 20Hz-20kHz(±0.1dB)
DNR @No-wt: 119dB@1kHz
Headphone (high gain mode) Output level(Vrms): 2.8Vrms@0dBFS
Maximum undistorted power: 26 mW@300Ω
THD+N@A-wt: 0.00016%@1kHz(-116dB@1kHz)
THD+N@No-wt: 0.00016%@1kHz(-116dB@1kHz)
Noise@No-wt: <2uVrms
SNR@No-wt: 124dB@1kHz
Frequency response): 20Hz-20kHz(±0.1dB)
DNR @No-wt: 124dB@1kHz
Power Input AC 110~240V 50/60Hz
Rated Power 9W
Dimensions 270mm(W) * 187mm(D)* 50mm(H)
Packing List Remote control*1, power cable*1, USB cable*1, product manual*1
